Pyrobel 16, 25, 35 & 53

Pyrobel is a range of fire resistant laminated glass, fire resistant and fire insulating class EI30 to 120 min. This transparent laminated glass is composed of clear float glass and intumescent interlayers. In case of fire, at approximately 120°, the interlayers transform  into a rigid and opaque screen which prevents the passage of flames and blocks the heat transfert.

Advantages

  • Transparency : transparent laminated glass with no wire mesh, its light transmission is equivalent to the same thickness float glass
  • Stability : the glass do not melt
  • Flame containment : the fire does not spread
  • thermal insulation, the average glass temperature on the protected side remains under 140 °C, which eliminates the risk of self combustion by radiation or convection of exposed materials and allows for safe evacuation
     of the building.

  • Safety, it is safety laminated glass (can be used as a safety balustrades under the conditions listed inthe test report) and helps keep panic to a minimum during a fire evacuation because it becomes opaque


  • Fire resistant clear laminated glass partitions: Pyrobel Vision line
  • Fire resistant glass for doors and partitions


To read more select a picture
  • suitable for large dimensions and wood frames

  • Short delivery time : available in 16, 25, 35& 53 mm thick

  • They can be assembled in double insulating units Vim Pyro  and with the same level of fire resistance add thermal insulation properties or incorporate a blind

Applications

Indoor and outdoor use in buildings that must comply with fire codes and regulations : as a single pane glass for doors, partitions, wood or steel fixed frames and double glazed for fire resistant doors ,windows , facades and  glass roofs.

The fire protection rating is guaranteed only if the glass is installed according to the instructions in the test reports. The structure must strictly comply with all aspects of the test report and its field of application.
  Fire resistant glass features:
--------------------------------
Pyrobel range

More informationFire resistance : E, EW & EI
